FUTABA Sky Leaf Samba f User Manual

9
Ŕ
Ŕ
Ŕ
Ŕ
ŔŔ
ś
Ś
Ŝ
Ŕœ
● Adjustthelengthoftherod.
Wing
ᵲᶆᶃᴾᵿᶇᶐᶎᶊᵿᶌᶃᴾᶕᶇᶊᶊᴾᶄᶊᶗᴾᶀᶃᶑᶒᴾᶕᶇᶒᶆᴾ
ᶔᶃᶐᶗᴾᶑᶋᶍᶍᶒᶆᴾᵿᶇᶊᶃᶐᶍᶌᴾᶍᶎᶃᶐᵿᶒᶇᶍᶌᵌᴾ
Aileron
● Bothwingsarebuiltsimilarly.
● Placetheaileronservosinposition
anduseadrilltomakethemounting
holesforyourservosintothewing.
● Aservoarmisscrewedonthetopofa
servohorn.
● Prepareaileronservowitha100mm
extension.
100mmExtension
ServoArm
ServoHorn
M2 × 5TappingScrew
● Useyourradiotocenteryouraileronservos.
Attachaservoarmtoeachservosothatthearm
isparallelwiththehingelinewhentheservo
iscentered.Installthearmssothattheypoint
outwardtowardthewingtip.
● Usetheinside
hole.
● Installtheaileron
servosusingthe
screwsprovidedwith
yourservos.
● Aservoleadwireistakenoutof
theholethroughthewinginterior.
!Thetheraisedballlinkon
theservoside.
M2Washer
BallLink
BallLink
M2Nut
M2 × 10Hexheadbolt
!Thetheraisedballlinkon
theservoside.
RaisedBallLink
M2 × 12Hexheadbolt
M2 × 10Hexheadbolt
AileronRod
M2Washer
M2Nut
SkyLeafTip
