FUTABA SkyLeaf BP - Page 22

22
Canopy
12
2
1
7
4
Whensilicone
adhesiveisapplied
betweenWheelpants
andgear,durability
improves.
IfWheelpantsandwheels
interfere,cutWheelpants.
2 21 2
● M3x16Hexagonbolt
isinstalledfromabove.
ŰŖŃƛŃŔřŃūƈƛƄƊƒƑŃƅƒƏƗŃ
ŰƄƌƑŃƊƈƄƕ
● Insertscrewsfrombetween
theslitsofthefuselagebottom
woodplate.
● WheelpantsontheleftandrightWheel.
5
6
● PutonWheelpantswithtwo
M2 × 8TappingScrews.
● ParalleltheFuselageand
theWheelpants.
● Adhesionofthecanopyshoulduseelastic
siliconeorrubberadhesive.
● AdheretheCanopytothefuselage.
● Peeloffthemaskingtapewhenthe
adhesiveisfixed.
●FixtheCanopywithaMaskingtape
untiltheadhesiveissolidified.
● InstallMaingearwithM3x16Hexagonbolt
6piecesandM3Washer6pieces.
