FUTABA SkyLeaf BP - Page 25

25
Wing
・
Strut
15
2
2
2
4
2
1
2
3
5
● BottomWingInsertthetwofrontdowelsinto
thetwoholesofFuselage.
● FixBottomWingwithtwoM4 × 35Flatheadscrews.
● FixStrutbasewithM3 × 35Flatheadscrew.
M3 × 35Flatheadscrew
M3 × 35Flatheadscrew
● FixUpperWingwithtwoM4 × 35Flatheadscrews.
● InstallStrutand
securewithL-wire
andStopper.
● TightenSetscrew
● LargeStrutbase
toBottomWing
● SmallStrutbase
toUpperWing
SkyLeafTip
ŵƈƐƒƙƈŃźƌƑƊŃ ƚƋƈƑŃ
ƗƕƄƑƖƓƒƕƗƌƑƊŃƄƑƇŃ ƖƗƒƕƌƑƊőŃ ŬƗŃ
ƌƖŃƆƒƑƙƈƑƌƈƑƗŃƗƒŃƕƈƐƒƙƈŃƒƑƏƜŃ
ƅƒƗƗƒƐŃƗƋƈŃůŃ ŐŃƚƌƕƈŃƗƋƈƑŃ ƉƒƏƇŃ
ƗƋƈŃŶƗƕƘƗŃƄƗƗƄƆƋƈƇŃ ƗƒŃƗƋƈŃ
ŸƓƓƈƕŃźƌƑƊő
BesuretoattachStrutwhenflying.
Ŷ7KHUHLV DGDQJHURI EUHDNGRZQLQWKHDLUGXHWRLQVXIILFLHQW
VWUHQJWKXQOHVVVWUXWLVDWWDFKHG
● AdheretheStrutbaseto
thewingwithSilicone
glueorRubberglue.
Stopper
L-wire
L-wire
● AttachtheStruttotheotherwingby
thesamework.
