FUTABA SkyLeaf BP - Page 28

28
C.G. Position
20
Adjustment of side thrust
21
● Flightandadjustthesidethrust.Ifdriftisaconcern,adjustthesidethrustwiththewasherinthemount.
● Verticalclimbwithfullpoweraftertrimadjustment.
● Alwaysdrifttotheleft,
increasetherightside
thrust.
● Alwaysturntotheright,
decreasetherightside
thrust.
！ Flightsetting
whenthereis
nowind.
● Withthewingslevel,haveanassistanthelp
youliftthemodelbythepropellershaftand
thebottomofthefuselageunderthetail.
Ifonewingalwaysdropswhenyouliftthe
model,itmeansthatsideisheavy.Balance
themodelbyaddingweighttotheother
wingtip.
● Withthewingattachedtothefuselage,all
partsofthemodelinstalled(readyfly)and
installedbattery.
Donotflybeforeconfirmingthe
correctlocationoftheC.G.
Ŷ,IWKH&*LVLQFRUUHFWWKHPRGHOZLOOIO\
EDGO\DQGFRXOGOHDGWRDFUDVK
●
5.1in(130mm)
● Ifyoufounditnecessary
toaddanyweight,recheck
theC.G.aftertheballast
weighthasbeeninstalled.
● Ifthetaildrops,themodelis"tailheavy"andthebatteryand/orreceivermust
beshiftedforwardorweightmustbeaddedtothenosetobalance.Ifthenose
drops,themodelis"noseheavy"andthebatteryand/orreceivermustbeshifted
aftorweightmustbeaddedtothetailto
balance.
