Example of setting S.BUS servo with T18MZ / T12K
3
Thisaircraftisequippedwithfouraileronservos,soitisconvenienttouseS.BUS.Inadvance,
decidetheservotobeusedandsettheS.BUSServosettingforeachchannelshownbelow.
ThispageisunnecessarywhenS.BUSisnotused.
Putthenameonthelabelandpasteitoneachservo.
ChannelsettingexamplewhenS.BUSisused:T18MZ
ChannelsettingexamplewhenS.BUSisused:T12K
WingType→4AIL+2FLP
TailType→AILVATOR
AIRPLANE
WING→4AIL+2FLP
TAIL→AILVATOR
AIRPLANE
CH1
Left
Aileron
CH6
Right
Aileron
CH4
Right
Aileron
CH5
Left
Aileron
CH12
Right
Elevator
CH2
Left
Elevator
CH3
Rudder
CH11
Throttle
CH1
Left
Aileron
CH8
Right
Aileron
CH6
Right
Aileron
CH7
Left
Aileron
CH5
Right
Elevator
CH2
Left
Elevator
CH4
Rudder
CH3
Throttle
◆ModelType
T18MZsetting
◆ModelType
T12Ksetting
ChangetoMODEＤ
◆CHMODE
R3008SB
IncaseofEP
EP:Motorcontroller
connectedtoCH3port.
EP:Motorcontroller
connectedtoCH3port.
Writethechannelto
theservowithS.BUS
Servo.
！ForEPwithT12K:Ifmodeltypeis4AIL+2FLP,throttlewillbeCH11.ThereisnoCH11output
portinthereceiver(defaultsetting),soyouneedtosetCHMODEtoMODEDandchangethe
receiver'sCH3porttoCH11output.
