FUTABA SkyLeaf Leader - Page 6

Installationofaileron,elevator,rudder,hinge
Installationofaileronservomount
Theexplanationisshowingtheaileronasanexample,butattachtheelevatorandrudderhingeinthe
sameway.
InserthalfthehingeintotheaileronandadheretheCAglue.Afterdrying,inserttheaileronintothemain
wingandpourtheCAglueintothehinge.Thereshouldbenoclearancebetweenthemainwingandthe
ailerons.
Afterdrying,checkthattheaileronmovessmoothly.
Cutthefilmoftheaileronservomountingholeofthemainwing.Removetheaileronservomountingbase
fromtheincludedpre-cut3mmwoodplateandpaintthecoloraccordingtoyourpreference.Inthesample
itispaintedwhite.Tracetheservomountontothefilmusingathinmarker.Stripoutthefilm1mminward
andremoveit.AdheretheservomountwithCAglue.
1
3
21
4
