FUTABA SkyLeaf Leader - Page 7

2
Installationofaileronservo.Aileronlinkage
Recommendation:BLS173SVi×4,EXTcode200mm×4,S.BUSHUB120-70×2
Cutthefilmattheexitoftheservowireinthecenterofthemainwing.Passtheservowireinsidethemain
wing.Itisalsoagoodmethodtoguidewithaweightedstring.
Attachtheaileronservotothemountwithatappingscrew.
Attachthecontrolhorntotheailerons.
Usingtheguide-#7(photo),firstmakeaholewitha2mmdrillandthencreateamountingholeforthe
controlhorn.Todeterminethepositionofthecontrolhornwithreferenceto#8.
Maketheaileronlinkage.#9-#11
Cutthefilmoftheholeswithstrutsonthemainwing.
5 6
7 8
