Recommendation:BLS173SVi×2
Theservoismountedinsidethehorizontalstabilizer.First,connecttheservotothereceiverandplaceitin
theneutralposition.
AttachHornAtotheservo,findthearmthatisabout15degreesforwardandcutofftheotherextraarm.
Removetheservohornandplacetheservoonthehorizontalstabilizer.Whilecheckingthepositionwhere
theservohornexitsthehorizontalstabilizer,openthehorndriveholeinthehorizontalstabilizer.
Maketheelevatorlinkage.
Installationofelevatorservo.Elevatorlinkage
9
10
11 12
13 14
