14
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
ŷƕƄƑƖƐƌƗƗƈƕŃůƌųƒŃƅƄƗƗƈƕƜŃůŷŕũŕœœœť
ŬƑƖƗƄƏƏƌƑƊŒƕƈƐƒƙƌƑƊŃƗƋƈŃůŷŕũŕœœœť
Removethe
batterycover
Batteryport
Insertthewiring
intothisspace.
Batterycover
PresstheOPEN
partofthebattery
cover.
Installthebattery
intothetransmitter
LT2F2000B
LiPoBattery
Thisconnectorconnectsto
thetransmitter.
Tab
Connectthebattery
connector
Becarefulnottopinch
thewiring
Closethebatterycovercompletely
