FUTABA T26SZ - Page 19

19
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
ŶƗƌƆƎŃƄƇƍƘƖƗƐƈƑƗ
$GMXVWPHQWRIWKHVWLFNOHYHUDQJOH
You can make fine adjustments to the angle of a stick
lever either inwards or outwards from the center stick
position.
Use the attached 1.5 mm hexagonal wrench (inside
stylus) to turn the screw clockwise to adjust the stick
outwards, or counter-clockwise to tilt it inward.
Note:
Be careful not to turn the screw too far counterclockwise
as it could fall out.
ŤƇƍƘƖƗƐƈƑƗŃƒƉŃƗƋƈŃƏƈƙƈƕŃƏƈƑƊƗƋ
You can adjust the length of stick levers, if you like. It is recommended to adjust the length of the sticks
in line with your hand size.
LeverheadA
LeverheadB
Screw
ūƒƚŃƗƒŃƄƇƍƘƖƗŃƗƋƈŃŶƗƌƆƎŃƏƈƑƊƗƋő
1.
Hold the lever head "B" and turn the lever head "A"
counter-clockwise, the lock will be released.
2.
Adjust the stick lever to the desired length by turning
lever head A.
3.
Securely lock the stick lever by holding lever head A
and turning lever head B counterclockwise.
