GyrosettingCGY770R
 FlightTune（Aileron/ElevatorBasicsettings）
 FlightTune（Aileron/ElevatorBasicsettings）
Note:Toeffectivelyoperatethenext"ELEComp"
(elevatorcorrection),makesuretoset"PitHigh",
"PitZero","PitLow"onthe"SWASHBASIC"menu.
(7) ELE. Comp: Elevator pre compensation
Ahelicopterthathasaheadthatrotatesclockwise,willexhibitatenden-
cywherebythenosewillbepulledtowardsthediskwithpositiveblade
pitch.Conversely,thehelicopterwillpushthenoseawayfromtherotor
diskduringnegativepitchinputs.Inaninstanceofaslowerservoset-up
orlarger(heavier)rotorblades,asmallamountofelevatorprecompen
-
sationmaybeneededtokeepthenoseofthehelicopterflatatalltimes
duringcollectivepitchchanges.Inmostcaseswithhelicopterhigh-
speedservosandstandard3Drotorblades,thisfunctionisnotneeded.
Ifyoudonotice aslighttendencyforthe nosetotrytoriseorfallwith
collectiveinput,increasing"ELEComp"willreducethisbehavior.
Settingranges:0~100%Initialvalue:0%
(8) HP. Auth.: High pitch authority
Whenarotorbladesangleofattackisincreased,therotorbladebecomes
lessreactive,inturnthehelicoptermightnotfeelasreactiveathighpitch
angles.Ifyouwanttoincreasethereactionofthecyclicduringloaded
andhighpitchmaneuvers,"HP.Auth"willincreasecontrolauthorityand
canbeusedtomakethehelicopterfeelmorelinearunderloading.Some
helicopterswithdirectlinkCCPMmayusethistoincreasestabilityat
highcollectivepitchflyingaswell.Ifahelicopterfeelsgoodfornormal
flying,butnotthesameduringloadedsituations,"HP.Auth"canbeused
tomakeitfeelmorelinear.If"HP.Auth"issetveryhigh,thehelicopter
willfeelmoreaggressiveathighpitchthanaroundneutral.
Settingranges:0~100%Initialvalue:HP.Auth=0%
