Future Design FDC-C22 User Manual

FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 12 of 20
141 E1FN Event input 1 function
NoNE: none
SP2: SP2 activated to replace SP1
rS.A1: Reset alarm 1 output
rS.A2: Reset alarm 2 output
rS.A3: Reset alarm 3 output
rS.A4: Reset alarm 4 output
rS.Ao: Reset all alarm outputs
CA.LH: Cancel alarm latch
d.o1: Disable output 1
d.o2: Disable output 2
d.o12: Disable output 1 and 2
LoCK: Lock all parameters and Read only communication
AU.MA: Switch Auto and Manual control mode
F.tra: Failure Transfer
AL.oN: EI Control Alarm Output
142 E2FN Event input 2 function
SP3: SP3 activated to replace SP1
Others: Same as E1FN
143 E3FN Event input 3 function
NoN
E
: none
SP4: SP4 activated to replace SP1
rS.A1: Reset alarm 1 output
rS.A2: Reset alarm 2 output
rS.A3: Reset alarm 3 output
rS.A4: Reset alarm 4 output
rS.Ao: Reset all alarm outputs
CA.LH: Cancel alarm latch
d.o1: Disable output 1
d.o2: Disable output 2
d.o12: Disable output 1 and 2
LoCK: Lock all parameters and Read only communication
AU.MA: Switch Auto and Manual control mode
F.tra: Failure Transfer
StAR: Run profile as RUN=STAR
CoNt: Run Profile as RUN=CONT
PV: Run Profile as RUN=PV
HoLd: Run Profile as RUN=HOLD
StoP: Run Profile as RUN=STOP
144 E4FN Event input 4 function
SP5: SP5 activated to replace SP1
Others: Same as E3FN
145 E5FN Event input 5 function
NoNE: none
SP4: SP4 activated to replace SP1
rS.A1: Reset alarm 1 output
rS.A2: Reset alarm 2 output
rS.A3: Reset alarm 3 output
rS.A4: Reset alarm 4 output
rS.Ao: Reset all alarm outputs
CA.LH: Cancel alarm latch
d.o1: Disable output 1
d.o2: Disable output 2
d.o12: Disable output 1 and 2
LoCK: Lock all parameters and Read only communication
AU.MA: Switch Auto and Manual control mode
F.tra: Failure Transfer
146 E6FN Event input 6 function
SP7: SP7 activated to replace SP1
Others: Same as E5FN
147 A1DL Alarm 1 Delay (Minutes: Seconds) Low: 00.00(OFF) High:99.59
148 A2DL Alarm 2 Delay (Minutes: Seconds) Low: 00.00(OFF) High:99.59
149 A3DL Alarm 3 Delay (Minutes: Seconds) Low: 00.00(OFF) High:99.59
150 A4DL Alarm 4 Delay (Minutes: Seconds) Low: 00.00(OFF) High:99.59
151 SFT Soft Start Time (Hours: Minutes) Low: 00.00(OFF) High:99.59
152 SPL1 Soft Start Power Limit for Output 1 Low: PL1L High:PL1H
153 SPL2 Soft Start Power Limit for Output 2 Low: PL2L Hi
g
h:PL2H
154 SFTH Soft Start Threshold Low: -19999 High:45536
155 SFTR Soft Start Timer (Hours: Minutes) Low: 00.00 High:99.59
