Future Design FDC-C22 User Manual

FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 11 of 20
110 BAUD Baud rate of digital communication
2K4: 2.4 Kbits/s baud rate
4K8: 4.8 Kbits/s baud rate
9K6: 9.6 Kbits/s baud rate
14K4: 14.4 Kbits/s baud rate
19K2: 19.2 Kbits/s baud rate
28K8: 28.8 Kbits/s baud rate
38K4: 38.4 Kbits/s baud rate
57K6: 57.6 Kbits/s baud rate
115K: 115.2 Kbits/s baud rate
111 DATA Data bit count of digital communication
7bIt: 7 data bits
8bIt:8 data bits
112 PARI Parity bit of digital communication
EVEN: Even parity
Odd: Odd parity
NoNE: No parity bit
113 STOP Stop bit count of digital communication
1bIt: One stop bit
2bIt: Two stop bits
114 CT1R Reading of CT 1 Low: 0.0 High: 150.0
115 CT2R Reading of CT 2 Low: 0.0 High: 150.0
116 HBEN Enable Heater break detection oFF: Off 1 oN: On
117 HBHY Heater break hysteresis Low: 0.1 High: 50.0
118 HB1T Triple point current for heater break 1 Low: 0.0 Hi
g
h: 120.0
119 HB2T Triple point current for heater break 2 Low: 0.0 Hi
g
h: 120.0
120 HSEN Enable Heater short detection oFF: Off 1 oN: On
121 HSHY Heater short hysteresis Low: 0.1 High: 50.0
122 HS1T Triple point current for heater short 1 Low: 0.0 High: 120.0
123 HS2T Triple point current for heater short 2 Low: 0.0 Hi
g
h: 120.0
124 RMSP Remote SP type
None:No Remote SP
4-20: 4-20mA retransmission output
0-20: 0-20mA retransmission output
0-5V: 0-5VDC retransmission output
1-5V: 1-5VDC retransmission output
0-10: 0-10VDC retransmission output
125 RINL Remote SP Input low scale value Low: -19999 High:RINH-50
126 RINH Remote SP Input hi
g
h scale value Low: RINL+50 Hi
g
h:45536
127 FILE Default File Selection
dFLt: Default Menu
Ld.Us: Load User Setting
St.Us: Store User Setting
128 PV Process value Low: -19999 High: 45536
129 SV Current set point value Low: SP1L High: SP1H
130 MV1 Output 1 percenta
g
e value
(
Heatin
g)
Low: 0.00 Hi
g
h: 100.00
131 MV2 Output 2 percentage value (Cooling) Low: 0.00 High: 100.00
132 PASS Password entry Low: 0 High: 9999
133 CODE Security code for parameter protection
Low: 0 High: 9999
0 = unprotected 1000 = user mode unprotected 9999=SPx (1
to 7) unprotected
134 OFTL Offset value for low point calibration Low: -1999 Hi
g
h: 1999
135 OFTH Offset value for high point calibration Low: -1999 High: 1999
136 CALO Input signal value during low point calibration Low: -19999 High: CAHI-1
137 CAHI Input signal value during high point calibration Low: CALO+1 High: 45536
138~139 … Reserved …
140 PROG Pro
g
ram code Same as PROG71
