Future Design FDC-C22 User Manual

FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 10 of 20
104 OFS2 Option function 2 selection
C82/C83/C72/C42:
NoNE: Not selected
CT1: CT1 input and Remote SP
CT1.2: CT1,CT2 inputs and Remote SP
C62:
NoNE: Not selected
EI1.2: Event input 1 and Event input 2
EI.CT: Event input 1 and CT2 input
CT1.2: CT1 and CT2 inputs
C22:
NoNE: No selected
4-20: 4-20mA retransmission output
0-20: 0-20mA retransmission output
0-5V: 0-5V retransmission output
1-5V: 1-5V retransmission output
0-10: 0-10 retransmission output
AL2: Alarm 2 output
R22:
NoNE: No selected
4-20: 4-20mA retransmission output
0-20: 0-20mA retransmission output
0-5V: 0-5V retransmission output
1-5V: 1-5V retransmission output
0-10: 0-10 retransmission output
AL2: Alarm 2 output
EI2: Event2 Input
CT2: CT2 Input
105 OFS3 Option function 3 selection
C82/C83/C42:
NoNE: Not selected
4-20: 4-20mA retransmission output & Remote SP
0-20: 0-20mA retransmission output & Remote SP
0-5V: 0-5VDC retransmission output & Remote SP
1-5V: 1-5VDC retransmission output & Remote SP
0-10: 0-10VDC retransmission output & Remote SP
A.4.20: Alarm 4, 4-20mA retransmission output & Remote SP
A.0.20: Alarm 4, 0-20mA retransmission output & Remote SP
A.0.5V: Alarm 4, 0-5V retransmission output & Remote SP
A.1.5V: Alarm 4, 1-5V retransmission output & Remote SP
A.0.10: Alarm 4, 0-10V retransmission output & Remote SP
C72:
NoNE: Not selected
4-20: 4-20mA retransmission output & Remote SP
0-20: 0-20mA retransmission output & Remote SP
0-5V: 0-5VDC retransmission output & Remote SP
1-5V: 1-5VDC retransmission output & Remote SP
0-10V: 0-10VDC retransmission output & Remote SP
AL4: Alarm 4 Output
C62:
NoNE: Not selected
4-20: 4-20mA retransmission output
0-20: 0-20mA retransmission output
0-5V: 0-5VDC retransmission output
1-5V: 1-5VDC retransmission output
0-10: 0-10VDC retransmission output
AL3: Alarm 3 output
106 RETY Retransmission type
RE.PV: Retransmit process value
RE.SP: Retransmit set point value
107 RELO Retransmission low scale value Low: -19999 High: 45536
108 REHI Retransmission hi
g
h scale value Low: -19999 Hi
g
h: 45536
109 ADDR Address assignment of digital communication Low: 1 High: 255
