Future Design FDC-C22 User Manual

FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 9 of 20
Modbus
Register
Address
Parameter
Notation
Parameter Description Range
95~102 SEL1~8 Select 1st~8th parameter for user menu
NoNE: No Parameter selected
dtMR: DTMR is moved to USER Menu
dISP: DISP is moved to USER Menu
Pb: PB is moved to USER Menu
tI: TI is moved to USER Menu
td: TD is moved to USER Menu
o1HY: O1HY is moved to USER Menu
RR: RR is moved to USER Menu
CPb: CPB is moved to USER Menu
db: DB is moved to USER Menu
A1HY: A1HY is moved to USER Menu
A1SP: A1SP is moved to USER Menu
A1dV: A1DV is moved to USER Menu
A2HY: A2HY is moved to USER Menu
A2SP: A2SP is moved to USER Menu
A2dV: A2DV is moved to USER Menu
A3HY: A3HY is moved to USER Menu
A3SP: A3SP is moved to USER Menu
A3dV: A3DV is moved to USER Menu
A4HY: A4HY is moved to USER Menu
A4SP: A4SP is moved to USER Menu
A4dV: A4DV is moved to USER Menu
PL1L: PL1L is moved to USER Menu
PL1H: PL1H is moved to USER Menu
PL2L: PL2L is moved to USER Menu
PL2H: PL2H is moved to USER Menu
OFTL: OFTL is moved to USER Menu
OFTH: OFTH is moved to USER Menu
CALO: CALO is moved to USER Menu
CAHI: CAHI is moved to USER Menu
A1DL: A1DL is moved to USER Menu
A2DL: A2DL is moved to USER Menu
A3DL: A3DL is moved to USER Menu
A4DL: A4DL is moved to USER Menu
103 OFS1 Option function 1 selection
C82/C83/C72/C42:
NoNE: Not selected
R485: RS-485 and Remote SP
C62:
NoNE: Not selected
R485: RS-485
C22/R22:
NoNE: Not selected
R485: RS-485
EI1: Event 1 input
CT1: CT 1 input
4-20: 4-20mA retransmission output
0-20: 0-20mA retransmission output
0-5V: 0-5VDC retransmission output
1-5V: 1-5VDC retransmission output
0-10: 0-10VDC retransmission output
