FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 5 of 20
3. PARAMETERS DESCRIPTION:
Modbus
Register
Address
Parameter
Notation
Parameter Description Range
0 SP1 Set Point 1 Low: SP1L Hi
h: SP1H
1 SP2 Set Point 2 Low: SP1L Hi
h: SP1H
2 SP3 Set Point 3 Low: SP1L High: SP1H
3 SP4 Set Point 4 Low: SP1L High: SP1H
4 SP5 Set Point 5 Low: SP1L High: SP1H
5 SP6 Set Point 6 Low: SP1L High: SP1H
6 SP7 Set Point 7 Low: SP1L Hi
h: SP1H
7 DTMR Dwell timer output time (Minute: Seconds) Low: 0.0 High: 4553.5
8 INPT Input sensor selection
J_tC: J type Thermocouple
K_tC: K type Thermocouple
T_tC: T type Thermocouple
E_tC: E type Thermocouple
B_tC: B type Thermocouple
R_tC: R type Thermocouple
S_tC: S type Thermocouple
N_tC: N type Thermocouple
L_tC: L type Thermocouple
U_tC: U type Thermocouple
P_tC: P type Thermocouple
C_tC: C type Thermocouple
D_tC: D type Thermocouple
Pt.dN: PT100 Ω DIN curve
Pt.JS: PT100 Ω JIS curve
4-20: 4-20mA linear current input
0-20: 0-20mA linear current input
0-5V: 0-5VDC linear voltage input
1-5V: 1-5VDC linear voltage input
0-10: 0-10VDC linear voltage input
9 UNIT Input unit selection
oC: °C unit
oF: °F unit
Pu: Process unit
10 DP Decimal point selection
No.dP: No decimal point
1-dP: 1 decimal digit
2-dP: 2 decimal digit
3-dP: 3 decimal digit
11 INLO Input low scale value Low: -19999 High:45536
12 INHI Input high scale value Low:INLO+50 High:45536
13 SP1L Low limit of set point value Low: -19999 High :45536
14 SP1H Hi
h limit of set point value Low: SP1L Hi
h:45536
15 FILT Filter damping time constant of PV
0: 0 second time constant
0.2: 0.2 second time constant
0.5: 0.5 second time constant
1: 1 second time constant
2: 2 second time constant
5: 5 second time constant
10: 10 second time constant
20: 20 second time constant
30: 30 second time constant
60: 60 second time constant
16 DISP MV/TIME display selection
None: No Display
MV1: Display MV1 (66/130)
MV2: Display MV2(67/131)
tIMR: Display Time (68)
PRoF: Display STAT(162) if have profile function
17 PB Proportional band value Low: 0.0 High: 500.0°C (900.0°F)
18 TI Integral time value Low: 0 High: 3600 sec
19 TD Derivative time value Low: 0.0 High: 360.0 sec
