Future Design FDC-C22 User Manual

FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 8 of 20
Modbus
Register
Address
Parameter
Notation
Parameter Description Range
56 A4MD Alarm 4 operation mode
NoRM: Normal alarm action
LtCH: Latching alarm action
HoLd: Hold alarm action
Lt.Ho: Latching & Hold action
SP.Ho: Set point holding alarm
57 A4HY Hysteresis control of alarm 4 Low: 0.1°C High: 50.0°C(90.0°F)
58 A4FT Alarm 4 failure transfer mode
OF
F
: Alarm output OFF if sensor fails
ON: Alarm output ON if sensor fails
59 A4SP Alarm 4 set point Low: -19999 High: 45536
60
A
4DV
A
larm 4 deviation value Low: -19999 Hi
g
h: 45536
61 BPL1 Bumpless transfer value of MV1 Low: 0.00 Hi
g
h: 100.00
62 BPL2 Bumpless transfer value of MV2 Low: 0.00 High: 100.00
63 CJCL Sense voltage during cold junction calibration low Low: 0 High: 7552
64 PV64 Process value Low: -19999 High:45536
65 SV65 Current set point value Low: SP1L Hi
g
h:SP1H
66 MV1 66 Output 1 %Value
(
Heatin
g)
Low: 0.00 Hi
g
h: 100.00 %
67 MV2 67 Output 2 %Value(Cooling) Low: 0.00 High: 100.00 %
68 TIMER Remaining time of dwell timer Low: 0.0 High: 4553.6
69 EROR Error code Low: 0 High: 65535
70 MODE Operation mode & alarm status Low: 0 High: 65535
71 PROG71 Program code
C22:22.XX C62:62.XX C82:82.XX C83:83.X
X
C72:72.XX C42:42.XX R22:23.XX
72 CMND Command code Low: 0 High: 65535
73 JOB1 Job code Low: 0 High: 65535
74 JOB2 Job code Low: 0 High: 65535
75 JOB3 Job code Low: 0 High: 65535
76 CJCT Cold Junction Temperature Low: -4000 High: 9000
77
A
DLO mV calibration low coefficient Low: -1999 Hi
g
h: 1999
78 ADHI mV calibration high coefficient Low: -1999 High: 1999
79 RTDL RTD calibration low coefficient Low: -1999 High: 1999
80 RTDH RTD calibration high coefficient Low: -1999 High: 1999
81 CJLO Cold junction calibration low coefficient Low: -5.00 High: 40.00
82 CJHI Cold junction calibration high coefficient Low: -1999 High: 1999
83 V1L V1 calibration low coefficient Low: -1999 Hi
g
h: 1999
84 V1G V1 calibration high coefficient Low: -1999 High: 1999
85 MA1L MA1 calibration low coefficient Low: -1999 High: 1999
86 MA1G MA1 calibration high coefficient Low: -1999 High: 1999
87 V2L V2 calibration low coefficient Low: -1999 High: 1999
88 V2G V2 calibration hi
g
h coefficient Low: -1999 Hi
g
h: 1999
89 MA2L MA2 calibration low coefficient Low: -1999 Hi
g
h: 1999
90 MA2G MA2 calibration high coefficient Low: -1999 High: 1999
91 PL1L Power limit 1 low Low: 0 High:PL1H or 50%
92 PL1H Power limit 1 high Low: PL1L High: 100 %
93 PL2L Power limit 2 low Low: 0 Hi
g
h: PL2H or 50%
94 PL2H Power limit 2 hi
g
h Low: PL2L Hi
g
h: 100 %
