Future light EVO-1 - DMX Controlled Operation; DMX Protocol Details

51837515_V_1_0.DOC
31/63
DMX-controlled operation
You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
DMX-protocol
Control channel 1 - Rotating gobo-wheel, gobo shake
Decimal Hexad. Percentage S/F Feature
0170011 0%7% SClose
18 35 12 23 7% 14% S Rot. gobo 1
36 53 24 35 14% 21% S Rot. gobo 2
54 71 36 47 21% 28% S Rot. gobo 3
72 89 48 59 28% 35% S Rot. gobo 4
90 111 5A 6F 35% 44% S Rot. gobo 5
112 127 70 7F 44% 50% F Gobo 1 shake with increasing speed
128 143 80 8F 50% 56% F Gobo 2 shake with increasing speed
144 159 90 9F 56% 62% F Gobo 3 shake with increasing speed
160 175 A0 AF 63% 69% F Gobo 4 shake with increasing speed
176 190 B0 BE 69% 75% F Gobo 5 shake with increasing speed
191 225 BF E1 75% 88% F Gobo-rotation with increasing speed
Control channel 2 - Gobo rotation
Decimal Hexad. Percentage S/F Feature
0 7 00 07 0% 3% S No rotation
8 255 08 FF 3% 100% S Rotation
Control channel 3 - Dimmer intensity
Decimal Hexad. Percentage S/F Feature
0 255 0 FF 0% 100% F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control channel 4 - Auto program
Decimal Hexad. Percentage S/F Feature
0 39 00 27 0% 15% S Normal
40 99 28 63 16% 39% S Reset
100 119 64 77 39% 47% S Auto Program 1
120 139 78 8B 47% 55% S Auto Program 2
140 159 8C 9F 55% 62% S Auto Program 3
160 179 A0 B3 63% 70% S Auto Program 4
180 199 B4 C7 71% 78% S Auto Program 5
200 219 C8 DB 78% 86% S Auto Program 6
220 239 DC EF 86% 94% S Auto Program 7
240 255 F0 FF 94% 100% S Auto Program 8
