Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply: 230 V AC, 50 Hz ~
Power consumption: 300 W
DMX-control-channels: 4
Rotating gobo-wheel: 5 gobos
Outside diameter of the gobos: 32 mm
Image diameter of the gobos: 27 mm
DMX-512-connection: 3-pin XLR
Sound-control: via built-in microphone
Dimensions (LxWxH): 360 x 300 x 290 mm
Weight: 10 kg
Maximum ambient temperature T
a
:
45° C
Maximum housing temperature T
B
(steady state):
70° C
Min.distance from flammable surfaces: 0.5 m
Min.distance to lighted object: 0.5 m
Fuse: F 3 A, 250 V
Accessory:
GE EHJ A1/223 24V/250W G-6.35 50h No. 88289000
OSRAM EHJ 64655HLX A1/223 24V/250W G-6.35 No. 88289010
FUTURELIGHT Easy-1 remote control No. 51834010
FUTURELIGHT EX-6/32 controller No. 51834046
FUTURELIGHT EX-8/32 controller No. 51834047
FUTURELIGHT CP-240 controller No. 51834265
FUTURELIGHT CP-256/64 controller 16bit No. 51834288
FUTURELIGHT CP-512/64 controller 16bit No. 51834295
Wizard-512 USB DMX-Software + Interface No. 51860102
Wizard-1024 USB DMX-Software + Interface No. 51860110
FUTURELIGHT DES-3 DMX-terminator 3-pin No. 51834001
Please note: Every information is subject to change without prior notice. 10.08.2006 ©
