DMX protocol
Mode/Channel Decimal Hexad. Percentage S/F Feature
St. Ex. 1 Ex. 2
1 1 1
Horizontal movement (PAN)
0 255 00 FF 0% 100% F
Push slider up in order to move the head
horizontally (PAN). Gradual head adjustment from
one end of the slider to the other (0-255, 128-
center). The head can be stopped at any position
you wish.
2 2
PAN-movement with 16-bit resolution
0 255 00 FF
0%
100% F
Fine indexing
2 3 3
Vertical movement (TILT)
0 255 00 FF 0% 100% F
Push slider up in order to move the head vertically
(TILT). Gradual head adjustment from one end of
the slider to the other (0-255, 128-center). The
head can be stopped at any position you wish.
4 4
TILT-movement with 16-bit resolution
0 255 00 FF
0%
100% F
Fine indexing
3 5 5
PAN/TILT speed
0 255 00 FF 0% 100% F Decreasing speed
6
PAN/TILT function
0 15 00 0F 0% 6% S Normal
16 31 10 1F 6% 12% S Blackout at PAN/TILT-movement
32 255 20 FF 13% 100% S No function
4 6 7
Shutter, strobe function
0 15 00 0F
0%
6% S
Normal Shutter Functions
16 31 10 1F
6%
12% S
Opening pulse-effect
32 47 20 2F
13%
18% S
Closing pulse-effect
48 63 30 3F
19%
25% S
Random strobe-effect
64 255 40 FF
25%
100% S
No function
5 7 8
Shutter, strobe
Normal Shutter Functions
0 31 00 1F
0%
12% S
Close
32 223 20 DF
13%
87% F
Strobe-effect with increasing speed
224 255 E0 FF
88%
100% S
Open
Opening pulse-effect
0 31 00 1F
0%
12% S
Close
32 223 20 DF
13%
87% F
Pulse-effect with increasing speed
224 255 E0 FF
88%
100% S
Open
Closing pulse-effect
0 31 00 1F
0%
12% S
Close
32 223 20 DF
13%
87% F
Pulse-effect with increasing speed
224 255 E0 FF
88%
100% S
Open
Random strobe-effect
0 31 00 1F
0%
12% S
Close
32 223 20 DF
13%
87% F
Strobe-effect with increasing speed
224 255 E0 FF
88%
100% S
Open
