Future light EYE-15 - Page 43

00075751.DOC, Version 1.1 43/54
88 129 58 81 35% 51% F Red increasing / green 100% / blue 0% / white 0%
130 171 82 AB 51% 67% F Red 100% / green decreasing / blue 0% / white 0%
172 213 AC D5 67% 84% F Red 100% / green 0% / blue increasing / white 0%
214 255 D6 FF 84% 100% F Red decreasing / green 0% / blue 100% / white 0%
13 15 16
White
0 255 00 FF 0% 100% F White 0 - 100 % increasing
LED segment E - color presets
0 0 00 00 0% 0% S Black
1 1 01 01 0% 0% S Red
2 2 02 02 1% 1% S Green
3 3 03 03 1% 1% S Blue
4 4 04 04 2% 2% S RGBW
5 45 05 2D 2% 18% F Red 0% / green increasing / blue 100% / white 0%
46 87 2E 57 18% 34% F Red 0% / green 100% / blue decreasing / white 0%
88 129 58 81 35% 51% F Red increasing / green 100% / blue 0% / white 0%
130 171 82 AB 51% 67% F Red 100% / green decreasing / blue 0% / white 0%
172 213 AC D5 67% 84% F Red 100% / green 0% / blue increasing / white 0%
214 255 D6 FF 84% 100% F Red decreasing / green 0% / blue 100% / white 0%
16
LED segment A - color presets
0 0 00 00 0% 0% S Black
1 1 01 01 0% 0% S Red
2 2 02 02 1% 1% S Green
3 3 03 03 1% 1% S Blue
4 4 04 04 2% 2% S RGBW
5 45 05 2D 2% 18% F Red 0% / green increasing / blue 100% / white 0%
46 87 2E 57 18% 34% F Red 0% / green 100% / blue decreasing / white 0%
88 129 58 81 35% 51% F Red increasing / green 100% / blue 0% / white 0%
130 171 82 AB 51% 67% F Red 100% / green decreasing / blue 0% / white 0%
172 213 AC D5 67% 84% F Red 100% / green 0% / blue increasing / white 0%
214 255 D6 FF 84% 100% F Red decreasing / green 0% / blue 100% / white 0%
17
LED segment B - color presets
0 0 00 00 0% 0% S Black
1 1 01 01 0% 0% S Red
2 2 02 02 1% 1% S Green
3 3 03 03 1% 1% S Blue
4 4 04 04 2% 2% S RGBW
5 45 05 2D 2% 18% F Red 0% / green increasing / blue 100% / white 0%
46 87 2E 57 18% 34% F Red 0% / green 100% / blue decreasing / white 0%
88 129 58 81 35% 51% F Red increasing / green 100% / blue 0% / white 0%
130 171 82 AB 51% 67% F Red 100% / green decreasing / blue 0% / white 0%
172 213 AC D5 67% 84% F Red 100% / green 0% / blue increasing / white 0%
214 255 D6 FF 84% 100% F Red decreasing / green 0% / blue 100% / white 0%
18
LED segment C - color presets
0 0 00 00 0% 0% S Black
