Future light PHS-200 - Page 30

51838165X87NXS_V_1_1.DOC
30/75
(1) Omega-holders
(2) Clamp
(3) Safety-rope
(4) Quick-lock fastener
Screw one clamp each via a M12 screw and nut onto the Omega-holders.
Insert the quick-lock fasteners of the first Omega-holder into the respective holes on the bottom of the
device. Tighten the quick-lock fasteners fully clockwise. Install the second Omega-holder.
DANGER TO LIFE!
Before taking into operation for the first time, the installation has to be approved by an expert!
