DMX-protocol
Control channel 1 - Horizontal movement (Pan) (within 360°)
Push slider up in order to move the head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be
stopped at any position you wish.
Control channel 2 - Vertical movement (Tilt) (within 265°)
Push slider up in order to move the head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be
stopped at any position you wish.
Control channel 3 - Pan/Tilt-speed
DMX-value Feature
0 Maximum speed
1-225 Decreasing speed
226-235 Blackout with Pan/Tilt-movement
236-245 Blackout with colour-change
246-255 No function
Control channel 4 - Colour-wheel
Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any
position. You need to activate this function via control channel 8.
DMX-value Feature
0-19 Open / white
20-39 Red
40-59 Dark blue
60-79 Dark green
80-99 Turquoise
100-119 Salmon pink
120-139 Yellow
140-159 Green
160-179 Pink
180-199 Light blue
200-255 Forwards rainbow effect with decreasing speed
Control channel 5 - Rotating gobo-wheel
DMX-value Feature
0-13 Open
14-27 Rot. gobo 1
28-41 Rot. gobo 2
42-55 Rot. gobo 3
56-69 Rot. gobo 4
70-83 Rot. gobo 5
84-97 Rot. gobo 6
98-115 Rot. gobo 7
116-135 Gobo 1 shake with increasing speed
136-155 Gobo 2 shake with increasing speed
156-175 Gobo 3 shake with increasing speed
176-195 Gobo 4 shake with increasing speed
196-215 Gobo 5 shake with increasing speed
216-235 Gobo 6 shake with increasing speed
236-255 Gobo 7 shake with increasing speed
