9. Operation of the chainsaw
The saw-chain starts to rotate as soon as the engine starts up, so make sure
there is sufficient safety clearance!
CHECKING THE OIL SUPPLY
After starting the engine, run the chain at
medium speed and check that the chain is
releasing oil, as shown in the figure.
(1) Chain oil
The amount of oil supplied can be regulated by
inserting a screwdriver into the opening at the
bottom of the coupling side. Adjust the oil supply
quantity according to working conditions.
(1) Chain oil flow adjustment screw
(2) Less oil
(3) More oil
NOTE
It is possible that the oil tank will also empty
during fuel consumption. Therefore, make sure
that the oil tank is filled every time the saw is
refuelled.
CARBURETTOR ADJUSTMENT
For the time being, adjust the L and H screw to
the factory setting by carefully closing them
completely to the right and screwing on the H
needle by ³/4 turn (± ³/8). Screw on the L
needle by 1.5 turn (± ³/8).
Start the saw and let it run at medium speed for
about half a minute (so it gets a little warm)
