FUXTEC FX-4MS131 - Technical Data

Original User Manual FX-4MS131_rev03
1. Technical data
Type FX-4MS131
Engine type
1E139F, air-cooled; 4-stroke
Cubic capacity
31cm
3
Maximum output power (kW)
(in accordance with ISO 8893)
0.8 kW / 6,000min
-1
The maximum speed of the engine
10,000 min
-1
Idle speed of the machine
3,000 ±200min
-1
LPA at the operator station
98dB(A) (K=3dB)
Guaranteed LWA
113dB(A)
Maximum vibration values on the left handle
6.090m/s
2
k=1.5m/s
2
Maximum vibration values on the right handle
6.789m/s
2
k=1.5m/s
2
Maximum diameter of the thread
Ф440mm (Φ2.5mm)
Rotation direction of the cutting device
Counterclockwise (see the mark on
the plate)
Number of the handle
2 pieces
Dry weight (kg)
7.2
Fuel tank capacity (ml)
750
Oil tank capacity (ml)
80ml
Oil
FUXTEC 4-stroke oil (SAE30)
Fuel consumption (kg/h) (in accordance with ISO
8893)
0.89
Specific fuel consumption (g/kWh) (in accordance
with ISO 8893)
380
Weight (net/gross) in (kg)
7.5 / 10.0
