Original User Manual FUXTEC FX-FSR152_rev05
12
5. Symbols on the device
WARNING
◆ For safe operation and maintenance, symbols are attached to the device.
Adhere to the instructions to avoid errors
The filler neck "Gasoline/2-cycle oil mixture 1/40
Position: Fuel filler cap
Set the switch to "|" position, the engine starts.
Set the switch to "O" position, stops the motor.
Position: right handle (on the left side)
Choke lever in this position closes the carburettor
Position: Air filter cover
Choke lever in this position means the carburettor is open
Position: Air filter cover
.
