Original User Manual FUXTEC FX-MS152 / FX-MS162
17
Installation of the lawn trimmer (thread spool)
Step 1:
Insert the key (1) into the hole in the gearhead so that the gear shaft is locked. Unscrew
and remove the nut. Since it is a safety nut, please make sure that there is a left-hand
thread here.
Step 2:
mount the lower spacer (here point 2, the same washer as above when mounting the
knife 2) and install the thread spool on the gear shaft. The remaining accessories, such
as the upper spacer washer/washer or the silver ring, are not required for mounting the
thread spool! Then tighten it by hand.
Warning!
Ensure that all components are correctly assembled and installed and that all screws are
tightened.
FUEL AND 2-STROKE OIL
Use unleaded petrol with 2-stroke engine oil in a 40:1 ratio. During the first few
operations, a mixture ratio of 25:1 can be selected to initially lubricate all device parts
optimally.
WARNING: Never use just fuel in your engine. This will cause permanent engine
damage and voids the manufacturer's warranty for this product. Never use a fuel
mixture that has been stored for more than 90 days.
WARNING: This must be a premium grade, 2-stroke air-cooled engine oil.
2
1
