Original User Manual FUXTEC FX-MT152/-MT152E/-MT252_rev16
35
little pressure. Do not work with a dull or damaged saw-chain. It increases physical
strain, increases vibrations, and leads to unsatisfactory results and higher wear and
tear:
 Clean the chain.
 Check it for broken links and damaged rivets.
 Replace damaged and worn chain parts with suitable spare parts, which you can
file to the shape and size of the original parts if necessary.
Observe the angles and dimensions given below. If the saw chain is not sharpened
correctly or the depth gauge is too small, there is a higher risk of kickback effects and
resulting injuries!
The saw chain cannot be fixed on the guide bar. It is, therefore, best to remove the
chain from the guide bar and then sharpen it.
 Select a sharpening tool suitable for chain pitch. See "Technical data" for the
approved chain pitches.
The chain pitch (e.g., 3/8") is marked in the depth gauge of
each blade.
Only use particular files for saw chains!
Other files have the wrong shape and grinding.
Choose the diameter of the file according to your
Chain pitch. Please also note the following
Angling when sharpening the chain knives.
A = filing angle
B = angle of the side plate
