FXA 501741206 - Part List

- 19 -
10. PART LIST
Pos. no.
Part no.
Description
Specification
Remark
Qty.
A
Part A
A-1
G3353000001
Brake Lever
Q235
Ø7.5mm
1
A-2
G3XW0000000
Limiting Stopper
PA66
1
A-3
G3320000000
Foam Pipe
NBR
20x510x3mm
1
A-4
G333F000001
Upper Handle
Q235
Ø22/t=1.35
1
A-5
B2011B00000
Nut
M6
2
A-6
G339X300000
Cable Fixing Clamp
PA66+GAF
1
A-7
G339XX60000
Brake Cable
G339XX60000
1
A-8
B1066B06032
Bolt
M6x32
1
A-9
G83B1000001
Lower Handle
Q235
Ø22/t=1.35
1
A-10
B1083W08045
Bolt
M8x45
4
A-11
B5019W00000
Flat Washer
Ø8.5xØ16x1.5mm
6
A-12
G33C1100010
Knob
PP
4
A-13
B2020W00000
Nut
M8
4
A-14
G33H0000000
Cable Support
PP
1
A-15
G33K0000000
Rope Guide
Q235
Ø6mm
1
A-16
B2009W00000
Nut
M8
2
A-17
G33J0000000
Handle Plug
PP
2
B
Part B
B-1
Y1200000019
Y100V Engine
C41
1
B-2
B1077W08025
Bolt
M8x25
3
B-3
BE004W00000
Flat Key
#45
4.775x5x20mm
1
B-4
G8530000000
Blade adapter
Q235
1
B-5
G8510000000
20" Blade
40MnB
t=3.5mm
1
B-6
G3520000000
Blade Washer
65Mn
t=3mm
1
B-7
B1001B00032
Blade Bolt
20Cr
3/8-24UNFx32
1
C
Part C
C-1
G8210000001
Deck
ST1.5
ST 1.5
1
C-2
G8240000010
Front Plastic Face
PP
1
C-3
B3023W00000
Screw
ST 4.8x15-C
3
C-4
B2007W00000
Nut
M5
2
C-5
G3250000000
Side Discharge Bracket
Q235
t=2mm
1
C-6
B1052W05010
Bolt
M5x10
2
C-7
G5260000000
Side Discharge Cover Shaft
Q235
Ø6mm
1
C-8
G8270000000
Side Discharge Cover Spring
1
C-9
G8280000000
Side Discharge Cover
PP
1
C-10
G8290000000
Side-Discharge Guiding Board
PP
1
D
Part D
D-1
B2009W00000
Nut
M8
8
D-2
B1010W08015
Bolt
M8x15
4
D-3
G8XX0000000
Right angle plate
4
D-4
B0019W00000
Bearing
12.7x28.6x8mm
8
D-5
G24G0000000
7" Wheel Assembly
PVC+PP
G42S
4
D-6
B6009B00000
Spring Washer
65Mn
Ø13xØ23.5x0.3x2.5mm
4
D-7
G8YY0000000
Bolt
Q235
4
D-8
G24R2000014
7" Wheel Cover
PP
P 109C
4
