FXA 501741206 - Technical Data

- 8 -
Wheels Assembly
- Put four wheels into corresponding wheel axle and tighten nuts, then fasten wheel covers on wheels.
Side Discharge Cover Assembly
- Lift the side discharge guard, install the side discharge cover.
Only Mulching: Please remove the side discharge cover.
3. TECHNICAL DATA
Model
501741206 / GL51KL-A
Engine type
Y100V
Engine Displacement
99 cm
3
Nominal Power
2.0 kW
Blade Width
508 mm
Rated Speed
2800/min
Gasoline Tank Capacity
0.80 L
Net Weight
22.4 kg
Height adjustment
25-75 mm, 4 adjustment
