3 POSITIONING
The super tweeter should be set back from the front of the loudspeaker
according to Table 1 and as illustrated by Fig. 2. This aligns it to the acoustic point
source location for these Fyne Audio models. For new models of loudspeaker
designs, please check our website for updates. If using with other brands of
point source driver, we suggest a similar placement according to driver size,
though some experimentation may be required to achieve the optimum results.
Signicantperformancegainsarestillapparentwithdiscretespeakersystems.
We recommend positing the super tweeter at the front of the cabinet with such
loudspeakers.
Table 1: PLACEMENT FOR VARIOUS FYNE AUDIO MODELS
PRODUCT POSITION
Classic VIII 50mm
Classic VIII Gold 55mm
Classic X 82mm
Classic X Gold 86mm
Classic XII 106mm
Vintage Ten 100mm
Vintage Twelve 139mm
Vintage Fifteen 154mm
F1-8 45mm
F1-8S 45mm
F1-10S 84mm
F1-12S 109mm
