Gaggenau DF211700 - Filter System

Cleaning and maintenance en-us
25
16.4 Filter system
The filter system removes coarse soiling from the dish-
washing cycle.
1
2
3
1
Micro filter
2
Fine filter
3
Coarse filter
Cleaning filters
Soiling in the dishwashing water may block the filters.
1. Check the filters for residue after each wash.
2. Turn the coarse filter anticlockwise and remove the
filter system ⁠.
‒ Make sure that no foreign objects fall into the sump.
1
2
3. Pull down the micro filter to remove.
4. Press the locking catches together and lift the coarse
filter out ⁠.
1
2
5. Clean the filter elements under running water.
Carefully clean the rim of dirt between the coarse and
fine filter.
6. Reassemble the filter system.
Make sure that the locking catches on the coarse filter
click into position.
7. Insert the filter system into the appliance and turn the
coarse filter clockwise.
Make sure that the arrow markings match up.
