Adjust method:
Note: Every time after the adjustment, before print another vertical calibration, it is required to tighten 3
screws on the carriage plate. Keep adjusting until the second pass is perfectly aligned with the first
pass.
3. Color offset: Color offset is to align all color in order to print good quality images.
Tip: Based on the "0" position, the color lines should totally matched with the Black line, if not, find the best one
showing on the printed out color offset, then input the corresponding values in the software. Note that values are
accumulated.
If the "0" position is not the perfect matching one, then we have to adjust the figure on the software. Go to Option
– Calibration – Color Offset
:
