6
3E3183 Gallagher HR5 Hand Held EID Tag Reader User Manual
English
FEATURES
Feature Descrip on
Trigger When in the ‘Read Tags’ (Collect) screen, pull the trigger
to begin reading tags.
Light The red light fl ashes when transmi ng and illuminates
con nuously when a tag is read.
Vibrator A single vibra on is felt in the handle with every
successful EID tag read.
Antenna The HR5 antenna has a read range of 27 - 33 cm.
Note: If there is more than one tag within range, neither
tag may be read.
USB
connector &
Dust cap
The supplied USB cable connects to the HR5 via the
connector beneath the dust cap. This cable enables:
• data to be transferred to/ from a computer
• the supplied USB charger to charge the internal
ba ery
Replace the dust cap when cable not in use.
Memory • Over 100,000 EID records can be stored in the HR5.
• When the memory is 90% full, a pop up warning will
be displayed.
• When the memory is full, no further tag reads will
be accepted un l one or more sessions have been
deleted.
Auto Power Down
The HR5 will power itself down a er 30 minutes of inac vity. This
se ng is only controlled via the APS so ware.
Screen
& Keypad
USB connector under Dust cap
Trigger
Light
Antenna
