5 LED indicaƟ ons
LED (squiggle) HBUS indicaƟ on
4 Rapid Flashes (Red) The controller that the reader is connected to is currently upgrading.
3 Flash (Amber) No communica ons with the Controller.
2 Flash (Amber) Communica ons with the Controller, but reader is not confi gured.
1 Flash (Amber) Confi gured to a Controller, but reader is not assigned to a door or elevator car.
On (Green or Red) Fully confi gured and func oning normally.
Green = Access mode is Free
Red = Access mode is Secure
Flashes Green Access has been granted.
Flashes Red Access has been denied.
Flashes (Blue) Reading a Gallagher mobile creden al.
LED (squiggle) Cardax IV indicaƟ on
3 Flash (Amber) No communica ons with the Controller.
On (Green or Red) Fully confi gured and func oning normally.
Green = Access mode is Free
Red = Access mode is Secure
Flashes Green Access has been granted.
Flashes Red Access has been denied.
6 Accessories
Accessory Product Code
T12 Dress Plate, Black, Pk 10 C300322
T12 Bezel, Black, Pk 10 C300288
T12 Bezel, White, Pk 10 C300289
T12 Bezel, Silver, Pk 10 C300290
T12 Bezel, Gold, Pk 10 C300291
T12 Spacer, Black, Pk 10 C300304
T12 Spacer, White, Pk 10 C300305
T11/T12 Protec ve Cover Spacer C300311
T11/T12 Protec ve Cover C300271
