7 Technical specifications
Routine maintenance:
Not applicable for this reader.
Cleaning:
This reader should be cleaned with mild
soapy water only. Do not use solvents or
abrasives.
Voltage:
9 Vdc – 16 Vdc
Current
3
:
Inactive
1
Active
2
T30 MIFARE Keypad Reader (at 9 Vdc):
145mA
340mA
T30 MIFARE Keypad Reader (at 13.6 Vdc):
92mA
221mA
T30 MULTI Keypad Reader (at 9 Vdc):
145mA
340mA
T30 MULTI Keypad Reader (at 13.6 Vdc):
92mA
221mA
Temperature range:
-30 °C to +70 °C (-22 °F to +158 °F)
4
Note: Direct sunlight may increase the
internal terminal temperature above the
ambient temperature level.
Humidity:
95% non condensing
5
Environmental protection:
IP68
Impact rating:
IK09
Unit dimensions:
Height 118 mm (4.6 in)
Width 86 mm (3.4 in)
Depth 25 mm (1.0 in)
Maximum number of readers on one HBUS cable:
20
Maximum number of terminals on one Controller 6000:
20
1
The terminal is idle.
2
A card is being read or the keys are at maximum brightness.
3
The current values stated above have been reported using the default configuration of an HBUS
terminal in Command Centre. Changing the configuration may vary the current value. Reader currents
verified by UL are provided in the document "3E2793 Gallagher Command Centre UL Configuration
Requirements".
4
Gallagher T Series readers are UL temperature tested and certified for operation in 0
o
C - 49
o
C
(indoor).
5
Gallagher T Series readers are UL humidity tested and certified to 85% and have been independently
verified to 95%.
