GAPOSA QC400 - Page 5

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
U
V
W
U
V
M
W
SAFETY
JUMPER
X5
X4
X1
X2
X8
X6
S3
S1
X7
X10
X9
X3
12 11 10 9 8 7 6 5 4 3 2 1
PLUG-IN RADIO
RECEIVER
QCMR500
ATTENTION!
In case of MECHANICAL
LIMIT SWITCHES
terminals 2 and 5 of the
connector X6 must be
jumped
OPEN
CLOSE
OPTICAL EDGE
BR.
GR.
WH.
PNE/8K2
EDGE
AUX1 NO
MAX 30V
MAX 50mA
STOP
GO
FUNC.
E.STOP
+
-
24 V
OUTPUT
SAFETY PHOTO
COM OL CL
N
SPEED
N
PULSE
SAFETY
CHAIN
+12V
GRD
ENCODER
DATA+
DATA-
+24V
ENCODER FOR
ELECTRONIC
LIMITS
+12V
GROUND
DATA +
DATA -
SAFETY
PULSE
12/24V
12/24V NA / NC
0V 0V
QCF4
PHOTOCELL
TX RX
OPEN BUTTON
MECHANICAL
LIMIT SWITCHES
CLOSE
LIMIT
OPEN
LIMIT
CL
OL
COM
S4
STOP BUTTON
CLOSE BUTTON
S2
OPTION SWITCH
CONN.
BROWN
GREEN
WHITE
QCLSM
PLUG-IN
TRAFFIC LIGHT
OPEN
CLOSE
PUSHBUTTON
BOX
PNE
8k2
YOU MUST
CONNECT ONLY
ONE SAFETY
EDGE TYPE
!
EMERGENCY
STOP
STOP
GO FUNCTION
U
PE
PE
PE
PE
3 PHASE
230/400VAC
MAINS POWER
1 PHASE
230VAC
MAINS CEE PLUG
PE NL3 L2 L1
L1 L3L2(N)
L1
V
M
W
ATTENTION!
MAINS VOLTAGE SELECT.
WRONG JUMPER PLACEMENT
CAN DESTROY THE CONTROL
VOLTAGE SELECT 230V~ 400V~
MAINS SUPPLY MAX 10mA
SETUP
PROGRAM
MEMBRANE KEYPAD
1~ 230Vac
U=OPEN
V=COMMON
W=CLOSE
3~ 230/400Vac
NOTE: PE must be connected first
and disconnected last if motor plug in terminals
are disconnected
1
2
3
4
5
6
7
8
9
10
ON DIP
AUX 1
SOLID STATE RELAY
SIGNAL OUTPUT
BROWN
GREEN
WHITE
QCSE OPTICAL
SAFETY EDGE
X16
!
5
