INSTALLATION PART 1: MOUNTING BRACKET
Step 3: Install The Mounting Bracket, cont.
Place the mounting bracket on the joist. Be sure
to align the mounting holes with the center of
the joist. With a pencil, mark an “X” on the
ceiling where you want the two holes to mount
your Lifter (Figure 1.3).
With a drill and the supplied drill bit, align the
bit on your marks and drill at least a 3" deep
pilot hole into the joist (Figure 1.4). The pilot
hole should drill through the sheetrock and into
the wood ceiling joist.
Fig 1.3
Fig 1.4
