INSTALLATION PART 2: POWER ADAPTER
Step 1: Placing Power Adapter
Find a suitable location to mount the power
adapter to the wall. Confirm that the AC
cable will reach a power outlet and the DC
cable will reach your MyLifter.
Use the printable screw template to place
the two wall mount screws into the desired
location (Figure 2.1) exactly 2 inches apart
(50.8 mm). Allow the screw heads to
protrude from the wall about ¼” (6.35 mm)
away from the wall. (Figure 2.2)
Fig 2.1
Fig 2.2
