2. INITIAL OPERATION v (Fig. A – D)
4. PROGRAMMING v (Fig. G – J)
Fig. G:
1 Set time (hours) | 2 Set time (mins) |
3 day setting (Mon ‒ Sun) | 4 Ready for schedule
Fig. H: 1 Select schedule | 2 Set schedule |
3 Confirm schedule | 4 Device programmed
Fig. I: Set = Sensor connected
Fig. J: 1 Active watering | 2 Change watering duration |
3 Stop active watering at any time
P1, P2, P3 denote watering schedules. You can
save up to 3 independent schedules. Schedules
can be activated or deactivated by pressing on / off
(see fig. H). During selection, selected watering
days are displayed as underlined weekdays.
In the standard display, only the selected days will
subsequently be shown. The current weekday
will be underlined.
By pressing the button, manual watering can
be started or stopped at a desired time (see fig. J ).
Connect soil moisture sensor (optional) fig. D:
After a sensor is connected, the “set sensor” dis-
play will appear – this can last for up to 1 minute.
By selecting 3-drip / 0-drip the sensor response will
be activated / deactivated. After successful activa-
A video of the
commissioning
and setting
processes is
available here:
3. FUNCTION v (Fig. F)
You can change the settings or move to the next
setting by turning the knob. You can confirm the
respective input by pressing the rotary knob.
Pressing the knob for a minimum of 3 seconds
locks or unlocks the display.
*
Battery
Condition *
Programs
Time
Connecting
sensor
Start Time
(0 – 23) hrs (0 – 59) min.
Run Time
0 hrs 1 min. –
3 hrs 0 min.
Frequency
(weekdays)
Watering
day
Active Watering
Timeplan
active /
deactive
SET
ON OFF
hrs min
Mo Tu We Th Fr Sa Su
Sensor
P1 P2 P3
Sensor
Sensitivity
The number of
drops represents
the measured
soil moisture.
max. 1 year
min. 4 weeks
max. 4 weeks
too weak for opening again
EN
6
