GardenMaster GM45CS3 - Page 11

11
Fig. A Fig. G Fig. H
6
22 8
Fig. B Fig. C
Fig. I Fig. J
7
12
Fig. F
25
2423
1
3
2
22
9
Fig.B
is in disengaged position.
1) Unscrew the chain bar locking nuts(8) with Chain
adjustment & Spark plug tool (19).
2) Pull off the clutch cover (22).
3) Install the Spiked bumper (7) to the power unit.
(Fig. B)
4) Put on the guide bar (12). (Fig. C)
5) Carefully remove the chain from the package. Hold
chain with the drive links as shown. Check the chain
direction. (Fig. D &E)
WARNING! Cutters must face in direction of
rotation.
6) Lift the chain over and behind clutch retainer, fitting
the drive links in the clutch drum sprocket. (Fig. F)
CAUTION: Do not insert the chain between the
chain sprocket and the disc.
7) Fit bottom of drive links between the teeth in the
front nose sprocket of the guide bar.
8) Fit chain drives links into chain bar groove (
1
). Place
the chain(24) over the chain catcher (23) on the bottom.
Fig. A Fig. G Fig. H
6
22 8
Fig. B Fig. C
Fig. I Fig. J
7
12
Fig. F
25
2423
1
3
2
22
9
Fig.C
Fig.D
Fig.E
Fig. A Fig. G Fig. H
6
22 8
Fig. B Fig. C
Fig. I Fig. J
7
12
Fig. F
25
24
23
1
3
2
22
9
Fig.F
