Part # P152 Rev 1 (01/13/10)Page 12
Miscellaneous
1. Grease the door hinges and check for loose fasteners.
Tighten as necessary.
2. Wire brush the surface of the griddle to remove baked
on material, wash with hot water, dry thoroughly. Lightly
coat the surface with vegetable oil to prevent rusting.
MAINTENANCE AND CLEANING continued
3. Wipe exposed cleanable surfaces with a mild detergent
and hot water. Stubborn residue may be removed with
a light weight non-metallic scouring pad. Stainless steel
areas should be washed with a mild detergent, hot water
and a soft cloth. If necessary use a nonmetallic scouring
pad always rub in the of the grain in the metal to prevent
scratching. NEVER USE STEEL WOOL.
4. Clean the oven racks shelves and guides with hot soapy
water and dry thoroughly. Clean the oven interior with a
propriety oven cleaner following instructions.
REPLACEMENT OF PARTS
Servicing must be carried out by competent persons in
accordance with the law.
WARNING: Turn o the electrical mains before commencing
any servicing work.
Door Switch
1. Drop the lower kick panel.
2. Remove the screws securing the door switch and
mounting brackets and remove screws securing the door
switch.
3. Remove the terminal cover and disconnect the wires
from the terminals on the body of the switch.
4. Replace the faulty door switch.
5. Make certain that the newly installed door switch is
properly adjusted so as the interrupt the power supply
to the control system and fan motor when the door is
opened.
Fan Cook/Cool Down Switch
1. Remove the screws securing the front panel to the front
rail and drop the panel.
2. Disconnect the wires from the terminals on the switch.
3. Depress the tabs of the switch body and push the switch
through the opening in the control panel.
4. Replace the switch and reassemble in reverse order.
Thermostat
1. Remove the screws securing the front panel to the front
rail and drop the panel.
2. Disconnect the wires from the taps on the thermostat.
3. Remove the dial from the thermostat and the screws
securing the thermostat body to the control panel.
4. Remove the wires from the thermostat terminals. Be sure
to note which wire connects to which terminal on the
thermostat.
5. Remove the thermostat bulb.
6. Replace the faulty thermostat and reassemble in reverse
order.
Heat On Lamp
1. Remove the screws securing the front panel to the front
rail and drop the panel.
2. Disconnect the supply wires to the lamp and remove the
faulty lamp.
3 Reassemble in the reverse order.
