Part # P152 Rev 1 (01/13/10)Page 14
TROUBLE SHOOTING continued
Oven Diagnostics
PROBLEM POSSIBLE CAUSE SOLUTION
Oven too hot or not hot enough. Thermostat out of calibration. Check Thermostat/replace thermostat.
RC Oven Diagnostics
PROBLEM POSSIBLE CAUSE SOLUTION
Cook/Cool Down Switch set to
“Cook position. Light o. Motor
not working.
No Power to Oven. Check power supply.
Defective Cook/Cool Down switch. Replace switch.
Faulty wiring. Check condition of wires and all connections.
Cook/Cool Down Switch set to
“Cook position. Light on. Motor
not working.
Defective door switch. Replace switch.
Oven door partially open. Close door.
Door switch out of alignment. Align switch.
Defective Motor. Replace Motor.
Faulty wiring. Check condition of wires and all connections.
Cook/Cook Down Switch set to
“Cook Position. Motor working,
thermostat set to temperature,
lamp on, oven not heating.
Relay RL1 is defective. Replace relay.
Defective heating element or wiring. Replace heating element or repair wiring.
Noisy motor. Blower wheel rubbing on oven baed. Adjust blower wheel.
Blower wheel loose on motor shaft. Retighten blower wheel.
Defective Motor. Replace Motor.
Cook/Cool Down switch set to
“Cool Down, motor not working.
Defective Cook/Cool Down switch. Replace switch.
Defective door switch. Replace switch.
Door switch out of alignment. Align switch.
Faulty wiring. Check condition of wires and all connections.
Oven too hot or not hot enough. Thermostat out of calibration. Check calibration/replace thermostat
Oven doors will not stay closed. Broken or damaged door spring. Replace door spring.
Sealed Hoptate Wattages and Applications
Application Boiling, Frying, Braising Simmering Warming
Dial Setting 6 5 4 3 2 1
8-5/8” (220mm) 2600W 1750W 1300W 450W 340W 240W
7” (180mm) 2000W 1400W 950W 450W 305W 200W
