Part # P152 Rev 1 (01/13/10)Page 18
MODEL
Phase grouping Loading chart
SS686 STD NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 18.65 208 9.20 4.60 4.85 58.51 59.43 39.35 89.66
X-Y Top 3 18.65 240 9.20 4.60 4.85 50.71 51.50 34.10 77.71
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 25.65 208 9.20 9.45 7.00 77.65 67.66 68.74 123.32
X-Y Top 2, Oven 25.65 240 9.20 9.45 7.00 67.30 58.64 59.58 106.88
Y-Z Salamander
SS686-1L
SS686-1C
SS686-12L
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 17.40 208 7.95 4.60 4.85 52.87 53.81 39.35 83.65
X-Y Top 3 17.40 240 7.95 4.60 4.85 45.82 46.64 34.10 72.50
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 24.40 208 7.95 9.45 7.00 72.54 62.29 68.74 117.31
X-Y Top 3, Oven 24.40 240 7.95 9.45 7.00 62.86 53.98 59.58 101.67
Y-Z Salamander
SS686-1R
SS686-12R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 17.40 208 7.95 4.60 4.85 52.87 53.81 39.35 83.65
X-Y Top 2 17.40 240 7.95 4.60 4.85 45.82 46.64 34.10 72.50
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 24.40 208 7.95 9.45 7.00 72.54 62.29 68.74 117.31
X-Y Top 2, Oven 24.40 240 7.95 9.45 7.00 62.86 53.98 59.58 101.67
Y-Z Salamander
SS686-2L
SS686-1C-12L
SS686-24L
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 16.15 208 6.70 4.60 4.85 47.32 48.29 39.35 77.64
X-Y Top 3 16.15 240 6.70 4.60 4.85 41.01 41.86 34.10 67.29
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 2, Top 3 23.15 208 6.70 9.45 7.00 67.57 57.05 68.74 111.30
X-Y Top 1, Oven 23.15 240 6.70 9.45 7.00 58.56 49.44 59.58 96.46
Y-Z Salamander
SS686-1R-12L
SS686-1L-12R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 16.15 208 6.70 4.60 4.85 47.32 48.29 39.35 77.64
X-Y Top 2 16.15 240 6.70 4.60 4.85 41.01 41.86 34.10 67.29
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 23.15 208 6.70 9.45 7.00 67.57 57.05 68.74 111.30
X-Y Top 2, Oven 23.15 240 6.70 9.45 7.00 58.56 49.44 59.58 96.46
Y-Z Salamander
SS686-2R
SS686-1C-12R
SS686-24R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y AZ A 1 phase
X-Z Top 2, Top 3 16.15 208 6.70 4.60 4.85 47.32 48.29 39.35 77.64
X-Y Top 1 16.15 240 6.70 4.60 4.85 41.01 41.86 34.10 67.29
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 2, Top 3 23.15 208 6.70 9.45 7.00 67.57 57.05 68.74 111.30
X-Y Top 1, Oven 23.15 240 6.70 9.45 7.00 58.56 49.44 59.58 96.46
Y-Z Salamander
SS686-2L-12R
SS686-1L-24R
SS686-2R-12L
SS686-1R-24L
SS686-36
SS686-1R-24L
S686 all models
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y AZ A 1phase
X-Z Top 1, Top 2 14.90 208 6.70 3.35 4.85 42.61 48.29 34.33 71.63
X-Y Top 3 14.90 240 6.70 3.35 4.85 36.93 41.86 29.75 62.08
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 21.90 208 6.70 8.20 7.00 62.14 57.05 63.35 105.29
X-Y Top 2, Oven 21.90 240 6.70 8.20 7.00 53.86 49.44 54.91 91.25
Y-Z Salamander 2
