Part # P152 Rev 1 (01/13/10) Page 25
MODEL
Phase grouping Loading chart
SS686RC STD NO SALAMANDER domestic (delta ) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 19.30 208 9.20 4.60 5.50 58.51 61.85 42.11 92.79
X-Y Top 3 19.30 240 9.20 4.60 5.50 50.71 53.60 36.49 80.42
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 26.30 208 9.20 10.10 7.00 80.39 67.66 71.59 126.44
X-Y Top 3, Oven 26.30 240 9.20 10.10 7.00 69.67 58.64 62.04 109.58
Y-Z Salamander
SS686RC-1L SS686RC-
1C SS686RC-12L
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 18.05 208 7.95 4.60 5.50 52.87 56.31 42.11 86.78
X-Y Top 3 18.05 240 7.95 4.60 5.50 45.82 48.80 36.49 75.21
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 25.05 208 7.95 10.10 7.00 75.33 62.29 71.59 120.43
X-Y Top 3, Oven 25.05 240 7.95 10.10 7.00 65.29 53.98 62.04 104.38
Y-Z Salamander
SS686RC-1R
SS686-12R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 18.05 208 7.95 4.60 5.50 52.87 56.31 42.11 86.78
X-Y Top 2 18.05 240 7.95 4.60 5.50 45.82 48.80 36.49 75.21
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 25.05 208 7.95 10.10 7.00 75.33 62.29 71.59 120.43
X-Y Top 2, Oven 25.05 240 7.95 10.10 7.00 65.29 53.98 62.04 104.38
Y-Z Salamander
SS686RC-2L SS686RC-
1C-12L SS686RC-24
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 16.80 208 6.70 4.60 5.50 47.32 50.88 42.11 80.77
X-Y Top 3 16.80 240 6.70 4.60 5.50 41.01 44.09 36.49 70.00
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 23.80 208 6.70 10.10 7.00 70.42 57.05 71.59 114.42
X-Y Top 3, Oven 23.80 240 6.70 10.10 7.00 61.03 49.44 62.04 99.17
Y-Z Salamander
SS686RC-1R-12L
SS686RC-1L-12R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 16.80 208 6.70 4.60 5.50 47.32 50.88 42.11 80.77
X-Y Top 2 16.80 240 6.70 4.60 5.50 41.01 44.09 36.49 70.00
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 3 23.80 208 6.70 10.10 7.00 70.42 57.05 71.59 114.42
X-Y Top 2, Oven 23.80 240 6.70 10.10 7.00 61.03 49.44 62.04 99.17
Y-Z Salamander
SS686RC-2R SS686RC-
1C-12R SS686RC-24R
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 2, Top 3 16.80 208 6.70 4.60 5.50 47.32 50.88 42.11 80.77
X-Y Top 1 16.80 240 6.70 4.60 5.50 41.01 44.09 36.49 70.00
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 2, Top 3 23.80 208 6.70 10.10 7.00 70.42 57.05 71.59 114.42
X-Y Top 1, Oven 23.80 240 6.70 10.10 7.00 61.03 49.44 62.04 99.17
Y-Z Salamander
SS686RC-2R-12L
SS686RC-2L-12R SS-
686RC-1L-24R SS686-
1R-24L SS686RC-36
S686RC all models
NO SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 15.55 208 6.70 3.35 5.50 42.61 50.88 37.21 74.76
X-Y Top 3 15.55 240 6.70 3.35 5.50 36.93 44.09 32.25 64.79
Y-Z Oven
WITH SALAMANDER domestic (delta) load Total kW voltage kW X-Z kW X-Y kW Y-Z A X A Y A Z A 1 phase
X-Z Top 1, Top 2 22.55 208 6.70 8.85 7.00 64.95 57.05 66.14 108.41
X-Y Top 3, Oven 22.55 240 6.70 8.85 7.00 56.29 49.44 57.32 93.96
Y-Z Salamander
