Garmin EDGE 530 User Manual

Replacing the Speed Sensor Battery
The device uses one CR2032 battery. The LED flashes red to indicate a low battery level after two revolutions.
1 Locate the circular battery cover on the front of the sensor.
2 Twist the cover counter-clockwise until the cover is loose enough to remove.
3 Remove the cover and the battery .
4 Wait 30 seconds.
5 Insert the new battery into the cover, observing polarity.
NOTE: Do not damage or lose the O-ring gasket.
6 Twist the cover clockwise so that the marker on the cover aligns with the marker on the case.
NOTE: The LED flashes red and green for a few seconds after battery replacement. When the LED flashes
green and then stops flashing, the device is active and ready to send data.
Device Information 57

Garmin EDGE 530 Specifications

General

Type	Wireless bicycle computer
Product color	Black
Time functions	Clock, Day time, Ride time
Speed functions	Average speed, Current speed
Ambient light sensor	Yes
International Protection (IP) code	IPX7
Internal memory	- GB
Routes quantity	100
Display diagonal	2.6 \
Display resolution	246 x 322 pixels
Battery type	Rechargeable Lithium-Ion
Battery life (max)	20 h

Weight and Dimensions

Depth	82 mm
Width	50 mm
Height	20 mm
Weight	75.8 g
