Specifications
Trolling Motor
Weight (motor,
mount, and cables)
50 in. model: 30 kg (66 lb.)
57 in. model: 31.75 kg (70 lb.)
Weight (stabilizer) 0.54 kg (1.2 lb.)
Operating
temperature
From -5° to 40°C (from 32° to 104°F)
Storage temperature From -40° to 85°C (-40° to 185°F)
Material Mount and motor housing: aluminum
Shaft cap, display panel, and side panels: plastic
Motor shaft: fiberglass
Water rating Shaft cap: IEC 60529 IPX5
2
Steering motor housing: IEC 60529 IPX7
3
Display panel housing: IEC 60529 IPX7
Propeller drive motor housing: IEC 60529 IPX8
4
Compass safe
distance
91 cm (3 ft.)
Power cable length 50 in. model: 1.2 m (4 ft.)
57 in. model: 1.1 m (3.5 ft.)
Input voltage From 20 to 45 Vdc
Input amperage 60 A continuous
Breaker (not
included)
42 VDC or greater, suitable for 60 A continuous
NOTE: You can protect the system buy using a
larger circuit breaker, not to exceed 90 A, if you
are operating under high temperatures or if you
are sharing the circuit with other devices. You
should verify that your boat wiring meets marine
wiring standards using a larger breaker before
changing it.
Main power usage at
36 Vdc 60 A
Off: 72 mW
Full power: 2160 W
Radio frequency 2.4 GHz @ 28 dBm nominal
Motor Thrust and Current-Draw Information
You can refer to these tables to understand the relationship
between the throttle level, output power, and current
consumption of the motor. These values assume you are using
an official Garmin power propeller, in relatively calm water, with
the motor deployed deeply enough not to ventilate, and with
tolerances of ±7 N-m (5 lbf) and ±5 A.
24.0 Vdc Power Source
Throttle Level Thrust Current
10% 25 N-m (6 lbf) 2 A
20% 45 N-m (10 lbf) 3 A
30% 70 N-m (16 lbf) 6 A
40% 101 N-m (23 lbf) 9 A
50% 140 N-m (31 lbf) 14 A
60% 184 N-m (41 lbf) 21 A
70% 233 N-m (52 lbf) 29 A
80% 287 N-m (65 lbf) 40 A
90% 345 N-m (78 lbf) 54 A
100% 355 N-m (80 lbf) 57 A
36.0 Vdc Power Source
Throttle Level Thrust Current
10% 21 N-m (5 lbf) 1 A
20% 41 N-m (9 lbf) 2 A
30% 69 N-m (16 lbf) 4 A
Throttle Level Thrust Current
40% 103 N-m (23 lbf) 6 A
50% 144 N-m (32 lbf) 10 A
60% 191 N-m (43 lbf) 15 A
70% 246 N-m (55 lbf) 21 A
80% 307 N-m (69 lbf) 29 A
90% 375N-m (84 lbf) 39 A
100% 445 N-m (100 lbf) 54 A
Remote Control
Dimensions (W×H×D) 152 x 52 x 32 mm (6 x 2 x 1
1
/
4
in.)
Weight 109 g (3.8 oz.) without batteries
Material Glass-filled nylon
Display type Sunlight-visible, transflective memory-in-pixel
(MIP)
Display resolution R240 x 240 pixels
Display size (diameter) 30.2 mm (1
3
/
16
in.)
Operating temperature From -15° to 55°C (5° to 131°F)
Storage temperature From -40° to 85°C (-40° to 185°F)
Battery type 2 AA (not included)
Battery life 240 hr., typical use
Radio frequency 2.4 GHz @ -0.8 dBm nominal
Water rating IEC 60529 IPX7
Compass-safe distance 15 cm (6 in.)
Foot Pedal
Dimensions (L×W×H) 303 × 221 × 110 mm (11
15
/
16
× 8
11
/
16
×
4
5
/
16
in.
Weight 1.8 kg (4 lb)
Operating temperature From -15° to 55°C (5° to 131°F)
Storage temperature From -40° to 85°C (-40° to 185°F)
Water rating IEC 60529 IPX7
Material Plastic
Input voltage From 10 to 45 Vdc
Typical input current < 1 mA @ 12 Vdc
Max input current 10 mA @ 12 Vdc
Fuse (on the power cable) 2 A mini-blade type
Power cable length 2 m (6.6 ft.)
Battery type Two AA batteries (Alkaline, NiMH, or
lithium. Not included.)
Battery life At least 1 year
Radio frequency 2.4 GHz @ 0.8 dBm nominal
Compass-safe distance 60 cm (2 ft.)
2
The part withstands projected water exposure from any direction (such as rain).
3
The part withstands incidental immersion in water up to 1 m deep for up to 30 min.
4
The part withstands continuous immersion in water up to 3 m deep.
10 Specifications
