INSTALLATION INSTRUCTIONS
GPSMAP 2006C/2010C & GPS 17
Final Wiring Connection
Once all the wiring is complete, plug the 18-pin harness into the center connector on the backside of the GPSMAP 2006/2010. The 5-pin port
on the right side is intended for future interfacing features and does not require connection at this time.
With power applied to the circuit, you may test the installation by pressing the
POWER key on the front of the unit. See the Owner’s
Manual for steps on initializing the receiver.
18-Pin Connector
5-Pin Connector
(for future use)
