Specifications
Specification Measurement
Dimensions (H x W x D) 186 x 190 x 264 mm (7.61 x 7.48 x 10.39 in.)
Weight 5.6 kg (12.25 lb.)
Temperature range From -15° to 55°C (from 5° to 131°F )
Material
• Electronics control unit (ECU): Fully gasketed aluminum alloy
• Bracket: Carbon steel
• Manifold: Aluminum alloy
• Motor: Aluminum alloy
Power cable length 2.7 m (9 ft.)
Input voltage
From 10 to 30 Vdc
Fuse 40 A, blade-type
Main power usage
• Standby: Less than 1 A
• Engaged: From 5 to 10 A
• Peak threshold: 30 A
Port and Fitting Specifications
Port, Fitting, or Plug Specification
H1 and H2 ports (top of manifold) SAE ORB-5 (2)
C1 and C2 ports (side of manifold) SAE ORB-5 (2)
T ports (side of manifold) SAE ORB-5 (2)
Included fittings for H and C ports SAE ORB-5 to
1
/
4
in. NPT straight (2)
Included fittings for T ports SAE ORB-5 to
1
/
4
in. NPT elbow (1)
Included plugs for unused ports SAE ORB-5 (3)
NOTE: Hose fittings must be purchased separately, if needed, to adapt from NPT to the hose type for each
installation. For example, most SeaStar
™
installations require SeaStar HF5528 or Parker
SM
68C-6-4 fittings. Most
Uflex and Verado
®
installs require Parker 4-4 FLO. Also, the included adapters can be removed to adapt directly
to SeaStar HF6009 or Verado 4-5 F5OLO hose fittings.
