INSTRUCTIONS
* j
Lay template on motor board
Prick through for positions of
4 FIXING HOLES
Mark round dotted line for
MOLE TO BE CUT IN MOTOR BOARD
Drill fixing holes
5/
ie dia.
AND CUT OUT CLEARANCE HOLE
